MUR1620 MUR1620CT MUR1620CTG MUR1640 MUR1640CT MUR1640CTG MUR1660 MUR1660CT MUR1660CTG 16A Ultra Fast Recovery Rectifier Diode

Overview of Mur200 Super Fast Recovery Diodes

The Mur200 series of super fast recovery diodes are designed for high-frequency switching applications in power electronics. These diodes feature a low forward voltage drop, which minimizes power loss and heat generation, along with an ultra-fast reverse recovery time that ensures efficient performance at high frequencies. They are widely used in switch-mode power supplies (SMPS), inverters, motor drives, and other power conversion systems where efficiency and reliability are critical.

Features of Mur200 Super Fast Recovery Diodes

1. Low Forward Voltage Drop: Reduces power dissipation and increases overall system efficiency.
2. Ultra-Fast Reverse Recovery Time: Minimizes switching losses and enhances performance in high-frequency circuits.
3. High Surge Current Capability: Ensures robustness against transient conditions.
4. High Operating Temperature Range: Supports stable operation over a wide temperature spectrum.
5. Compact Package: Facilitates easier integration into space-constrained designs.
6. High Reliability: Designed for long-term stability and durability in demanding environments.

(MUR1620 MUR1620CT MUR1620CTG MUR1640 MUR1640CT MUR1640CTG MUR1660 MUR1660CT MUR1660CTG 16A Ultra Fast Recovery Rectifier Diode)

Specification of MUR1620 MUR1620CT MUR1620CTG MUR1640 MUR1640CT MUR1640CTG MUR1660 MUR1660CT MUR1660CTG 16A Ultra Fast Recovery Rectifier Diode

The MUR1620, MUR1620CT, MUR1620CTG, MUR1640, MUR1640CT, MUR1640CTG, MUR1660, MUR1660CT, and MUR1660CTG are 16A ultra-fast healing rectifier diodes developed for high-efficiency power applications. These diodes are enhanced for use in changing power materials, inverters, freewheeling circuits, and snubbers, supplying reputable efficiency with very little changing losses. Trick specs include a peak repetitive reverse voltage (VRRM) of 200V (MUR1620 series), 400V (MUR1640 collection), and 600V (MUR1660 collection), guaranteeing convenience across different voltage demands. Each diode includes a typical forward existing (IF(AV)) of 16A, with a non-repetitive surge existing (IFSM) of 150A, offering toughness versus transient overloads. The ultra-fast healing time (trr) of 35ns (regular) and low reverse recovery charge (Qrr) ensure decreased switching sound and boosted performance in high-frequency applications. Ahead voltage drop (VF) is commonly 1.7 V at 16A, decreasing transmission losses. The diodes are offered in 3 plan variants: the standard TO-220AC (MUR16x0), TO-220AB (MUR16x0CT), and insulated TO-220AB (MUR16x0CTG). The insulated CTG alternative includes a thermally conductive but electrically isolated installing base, improving safety and security and heat dissipation in compact designs. Thermal resistance (RθJC) ranges from 1.92 ° C/W (TO-220AC) to 3.0 ° C/W (CTG protected package), supporting efficient thermal administration. Operating and storage temperatures cover from -65 ° C to +175 ° C, making sure reliability in extreme environments. These rectifiers abide by RoHS standards and appropriate for commercial, vehicle, and consumer electronics, consisting of UPS systems, motor drives, and DC-DC converters. The MUR16x0 collection integrates high rise capacity, low leak current (IR < 10µA at ranked VRRM), and ultra-fast recuperation, making them ideal for applications requiring precision and sturdiness. All versions are lead-free and halogen-free, lining up with worldwide ecological policies. For thorough electric qualities, describe the datasheet for certain part numbers, as criteria like reverse recuperation time and forward voltage might vary somewhat in between versions.

(MUR1620 MUR1620CT MUR1620CTG MUR1640 MUR1640CT MUR1640CTG MUR1660 MUR1660CT MUR1660CTG 16A Ultra Fast Recovery Rectifier Diode)

Applications of MUR1620 MUR1620CT MUR1620CTG MUR1640 MUR1640CT MUR1640CTG MUR1660 MUR1660CT MUR1660CTG 16A Ultra Fast Recovery Rectifier Diode

The MUR1620, MUR1620CT, MUR1620CTG, MUR1640, MUR1640CT, MUR1640CTG, MUR1660, MUR1660CT, and MUR1660CTG are 16A ultra-fast recovery rectifier diodes designed for high-efficiency, high-frequency applications. These diodes include ultra-fast recuperation times, reduced onward voltage declines, and high rise existing ability, making them suitable for use in power electronic devices where speed, integrity, and thermal performance are important. With reverse voltage rankings ranging from 200V (MUR16x0) to 400V (MUR16x0) and 600V (MUR16x0), these diodes cater to varied voltage demands. Their TO-220 and separated TO-220 (CTG) packages guarantee robust thermal administration and compatibility with typical installing systems.

** Secret Applications: **.
1. ** Changing Power Materials: ** These diodes are extensively used in AC-DC and DC-DC converters, particularly in freewheeling, securing, and outcome rectification stages. Their ultra-fast healing reduces switching losses, boosting efficiency in high-frequency switch-mode power supplies (SMPS) for servers, telecommunications equipment, and industrial machinery.

2. ** Inverters and Converters: ** In solar inverters, electric motor drives, and UPS systems, the MUR16xx collection takes care of high-speed changing to minimize power loss and heat generation. Their capacity to manage quick voltage transitions makes sure stable efficiency in renewable resource systems and electrical car charging infrastructure.

3. ** Automotive Electronic devices: ** These diodes are suitable for vehicle applications such as voltage regulation, alternator rectification, and LED lights drivers. Their sturdy design holds up against temperature level changes and electric sound, fulfilling the demands of modern-day electrical and hybrid vehicles.

4. ** Industrial Tools: ** Utilized in welding equipments, induction heating, and CNC electric motor drives, these rectifiers provide trustworthy efficiency in high-current, high-temperature environments. The reduced onward voltage drop minimizes power dissipation, improving system durability.

5. ** Customer Electronics: ** The diodes’ effectiveness and compact product packaging make them excellent for high-end power adapters, gaming consoles, and LCD/LED television power components, where room and thermal monitoring are top priorities.

** Advantages: **.
– ** Ultra-Fast Recuperation: ** Trr as low as 35ns makes sure marginal reverse recovery losses.
– ** High Surge Ability: ** Withstands non-repetitive surge currents up to 150A, boosting reliability in short-term conditions.
– ** Thermal Performance: ** Reduced thermal resistance (TO-220 versions) and optional separated packages (CTG) simplify heatsink assimilation.

These diodes incorporate high-speed performance with rugged building, making them a functional option for modern-day digital systems requiring performance, sturdiness, and precision. Whether in renewable resource, automobile, or industrial automation, the MUR16xx series supplies constant performance under demanding conditions.
