New&Oem(Original) Warranty 1 Year Vuo82-16no7 Three Phase Rectifier Bridge Module

Overview of Single Three Phase Rectification Bridge Modules

Single three phase rectification bridge modules are essential components in power electronics, designed to convert alternating current (AC) from a three-phase supply into direct current (DC). These modules typically consist of six diodes arranged in a bridge configuration. They are widely used in industrial applications such as motor drives, welding equipment, and uninterruptible power supplies (UPS) systems due to their efficiency and reliability. The robust design ensures stable operation under varying load conditions, while the compact size facilitates easy integration into various electrical systems.

Features of Single Three Phase Rectification Bridge Modules

1. High Efficiency: Optimized for minimal power loss during AC-to-DC conversion.
2. Compact Design: Saves space within electrical installations, making it easier to integrate into existing systems.
3. Robust Construction: Built to withstand harsh environments and provide long-term reliability.
4. Wide Operating Temperature Range: Capable of operating efficiently across a broad temperature spectrum, enhancing versatility.
5. Low Thermal Resistance: Facilitates effective heat dissipation, contributing to prolonged component life.
6. Overcurrent Protection: Integrated safety features protect against potential damage from excessive currents.
7. Simplified Wiring: Reduces installation complexity and time with straightforward connections.
8. High Surge Current Capability: Handles transient overloads without compromising performance or longevity.

(New&Oem(Original) Warranty 1 Year Vuo82-16no7 Three Phase Rectifier Bridge Module)

Specification of New&Oem(Original) Warranty 1 Year Vuo82-16no7 Three Phase Rectifier Bridge Module

The New & OEM (Initial) Service Warranty 1 Year VUO82-16NO7 Three-Phase Rectifier Bridge Module is a high-performance element developed for transforming three-phase alternating present (AIR CONDITIONING) to route existing (DC) in commercial and commercial applications. Built to OEM criteria, this module makes certain dependability, efficiency, and toughness under demanding conditions. It is backed by a 1-year initial manufacturer warranty, assuring defect-free materials and handiwork.

** Secret Specifications: **.
– ** Model: ** VUO82-16NO7.
– ** Type: ** Three-phase full-wave rectifier bridge.
– ** Maximum Repeated Opposite Voltage (VRRM): ** 1600V.
– ** Average Forward Current (IFAV): ** 82A.
– ** Surge Current (IFSM): ** 820A (non-repetitive).
– ** Onward Voltage Drop (VF): ** ≤ 1.1 V per bridge aspect at rated present.
– ** Running Temperature Range: ** -40 ° C to +150 ° C.- ** Storage Temperature Range: ** -40 ° C to +150 ° C.- ** Installing Technique: ** Screw or stud placing with shielded plan for very easy installment.
– ** Weight: ** About 200g.
– ** Capacities: ** Compact style, 50mm x 30mm x 20mm.
– ** Certifications: ** Certified with RoHS and ISO 9001 requirements.

** Features: **.
– ** Robust Construction: ** High-grade silicon rectifier chips and shielded metal substrate ensure optimum thermal efficiency and electrical isolation.
– ** High Performance: ** Low ahead voltage decline minimizes power loss, improving energy efficiency.
– ** Toughness: ** Engineered to withstand high surge currents, voltage spikes, and temperature variations.
– ** Safety: ** Fully insulated housing protects against unintentional call with online components.

** Applications: **.
Ideal for use in commercial electric motor drives, welding tools, power materials, battery chargers, CNC machinery, and renewable energy systems. Suitable for integration right into automation systems, hefty machinery, and auto production arrangements needing steady DC outcome.

** Warranty & Assistance: **.
This OEM-grade component consists of a 12-month warranty covering manufacturing issues. Technical support is readily available for installment guidance and troubleshooting.

The VUO82-16NO7 integrates OEM top quality with sturdy performance, making it an affordable service for high-power correction needs. Its compact size, high voltage/current rankings, and conformity with worldwide requirements make certain smooth compatibility and lasting dependability in varied environments.

(New&Oem(Original) Warranty 1 Year Vuo82-16no7 Three Phase Rectifier Bridge Module)

Applications of New&Oem(Original) Warranty 1 Year Vuo82-16no7 Three Phase Rectifier Bridge Module

The New & OEM Warranty 1 Year VUO82-16NO7 3 Phase Rectifier Bridge Module is a high-performance part designed for transforming three-phase rotating existing (AIR CONDITIONING) to direct current (DC) in commercial and commercial applications. With a durable building and an one-year OEM guarantee, this module guarantees integrity, efficiency, and durability in demanding settings. Its key applications span throughout power supplies, electric motor drives, industrial automation, renewable energy systems, and extra.

** Industrial Equipment and Motor Drives **: The VUO82-16NO7 is ideal for motor control systems, including CNC makers, conveyor systems, and heavy-duty commercial electric motors. It efficiently rectifies three-phase AC power to secure DC, making it possible for accurate rate and torque control in variable frequency drives (VFDs). Its high present capability (approximately 82A average ahead present) and voltage score (1600V) make it suitable for high-power applications.

** Power Supplies and UPS Systems **: In uninterruptible power products (UPS) and commercial power systems, this rectifier module guarantees constant DC output, critical for keeping functional connection in information facilities, health centers, and telecommunications framework. Its reduced ahead voltage decline reduces energy loss, boosting system performance.

** Renewable Energy Solutions **: The component is used in solar inverters and wind turbine systems to convert a/c created by generators or inverters into DC for battery storage space or grid combination. Its high thermal stability and surge existing tolerance make it trustworthy in varying energy settings.

** Welding Equipment and Battery Chargers **: For welding equipments and high-capacity battery chargers, the VUO82-16NO7 gives steady DC output, guaranteeing consistent performance and decreasing downtime. Its sturdy style stands up to high-temperature conditions usual in welding applications.

** Automotive and EV Charging **: In electric vehicle (EV) charging stations and automobile manufacturing, this rectifier supports high-power DC conversion for fast-charging systems and assembly line equipment.

** OEM Applications **: Original equipment suppliers take advantage of the component’s small design, easy integration, and compliance with global standards. The one-year service warranty assurances top quality, decreasing maintenance prices and making sure conformity with industrial safety and security norms.

Secret functions consist of reduced leakage existing, high insulation voltage (2500V), and a screw-terminal design for protected links. Whether upgrading existing systems or developing brand-new remedies, the VUO82-16NO7 delivers sturdiness and accuracy, backed by OEM guarantee for stress-free release.

Company Profile

PDDN Photoelectron Technology Co., Ltd.(sales@pddn.com) is one of the leading enterprises in power electronics technology and power products, which is fully involved in developing solar inverters， transformers, voltage regulators, distribution cabinets, thyristors， modules， diodes， heaters, and other electronic devices or semiconductors. We will be committed to providing users with high-quality, efficient products and considerate service.

It accepts payment via Credit Card, T/T, West Union, and Paypal. PDDN will ship the goods to customers overseas through FedEx, DHL, by sea, or by air. If you want high-quality New&Oem(Original) Warranty 1 Year Vuo82-16no7 Three Phase Rectifier Bridge Module, please send us inquiries; we will be here to help you.

Payment Methods

L/C, T/T, Western Union, Paypal, Credit Card etc.

Shipment

By sea, by air, by express, as customers request.

Storage Conditions

1) Store in a dry environment at room temperature.

2) Avoid damp and high temperature.

3) Use immediately after opening the inner packing bag.

5 FAQs of New&Oem(Original) Warranty 1 Year Vuo82-16no7 Three Phase Rectifier Bridge Module

What is the Vuo82-16no7 three-phase rectifier bridge module used for? The Vuo82-16no7 is designed to convert three-phase alternating current (AC) into direct current (DC) in industrial and commercial applications. It is commonly used in power supplies, motor drives, battery chargers, and other equipment requiring stable DC output. The module ensures high efficiency, low heat generation, and reliable performance under heavy loads, making it ideal for machinery, automation systems, and renewable energy setups.

Is the Vuo82-16no7 compatible with all three-phase systems? The module is compatible with most standard three-phase systems operating within its rated specifications. It supports a maximum repetitive reverse voltage of 1600V and an average forward current of 82A. However, compatibility depends on your system’s voltage, current, and frequency requirements. Always verify your application’s parameters against the module’s datasheet to ensure safe and optimal performance.

How do I install the rectifier bridge module? Installation requires mounting the module on a heat sink using thermal paste to ensure proper heat dissipation. Connect the AC input terminals (labeled R, S, T) to the three-phase power source and the DC output terminals (+ and -) to the load. Tighten terminals to the recommended torque (specified in the manual) and ensure wiring complies with local electrical standards. Avoid overloading or exposing the module to moisture.

What does the 1-year OEM warranty cover? The warranty covers defects in materials or workmanship under normal use for one year from purchase. It includes repairs or replacements for issues like internal component failure or manufacturing flaws. Damage from misuse, improper installation, overheating due to inadequate cooling, or unauthorized modifications voids the warranty. Retain your purchase invoice and contact the supplier for claims.

What should I do if the module fails or overheats? First, disconnect power and inspect for loose connections, overloads, or insufficient cooling. Ensure the heat sink is securely attached and the ambient temperature stays within the rated range (typically -40°C to +150°C). If the module still malfunctions, submit a warranty claim with proof of purchase. Do not attempt repairs, as disassembling the unit voids the warranty. For non-warranty issues, consult a certified technician.
